7500DWT SPB Construction Schedule7500DWT SPB Construction Schedule
| 文件编号 | 7710 | 工期 | 364天 | 开始时间 | 2018-09-18 | 结束时间 | 2019-09-16 |
| 任务数 | 81K | 整理日期 | 2019/5/17 | 下载次数 | 3887次 | ||
| 下载地址 | 计划文件点击下载(登录后才可以下载) | ||||||
计划内容
| 7500DWT SPB Construction Schedule | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
编号 |
Item No. |
Construction Period |
Starting date |
Finishing Date |
前置任务 |
资源名称 |
| 1 | Design设计 |
105天 | 2018-09-18 | 2018-12-31 | ||
| 2 | Drawings for approval图纸送审 |
149天 | 2018-10-18 | 2019-03-15 | ||
| 3 | Steel cutting开工 |
1天 | 2018-11-06 | 2018-11-06 | ||
| 4 | Hull Construction船体结构部分 |
262天 | 2018-11-13 | 2019-08-01 | ||
| 5 | Main hull Blocks fabrication主船体结构 |
186天 | 2018-11-13 | 2019-05-17 | ||
| 6 | Accommodation Blocks fabrication上键单元 |
60天 | 2019-04-02 | 2019-05-31 | ||
| 7 | Blocks assembly合拢 |
90天 | 2019-05-04 | 2019-08-01 | ||
| 8 | Seats for equipments设备基座 |
30天 | 2019-03-24 | 2019-04-22 | ||
| 9 | Support for equipments设备加强 |
30天 | 2019-06-08 | 2019-07-07 | ||
| 10 | Tanks inspection舱室密性 |
25天 | 2019-05-15 | 2019-06-08 | ||
| 11 | NDT |
38天 | 2019-05-13 | 2019-06-19 | ||
| 12 | Air test气密试验 |
20天 | 2019-05-27 | 2019-06-15 | ||
| 13 | Painting油漆 |
219天 | 2019-01-08 | 2019-08-14 | ||
| 14 | Blocks 分段 |
130天 | 2019-01-08 | 2019-05-17 | ||
| 15 | Painting defects fold up油漆修补 |
80天 | 2019-05-27 | 2019-08-14 | ||
| 16 | Fresh water tank淡水舱 |
30天 | 2019-05-22 | 2019-06-20 | ||
| 17 | Oil tank油舱 |
20天 | 2019-05-29 | 2019-06-17 | ||
| 18 | Launching下水 |
1天 | 2019-06-20 | 2019-06-20 | ||
| 19 | Main engine(propulsion system)主推进系统 |
75天 | 2019-04-24 | 2019-07-07 | ||
| 20 | Seating and support设备基座及加强 |
10天 | 2019-04-24 | 2019-05-03 | ||
| 21 | Installation安装 |
30天 | 2019-05-09 | 2019-06-07 | ||
| 22 | Commissioning调试 |
5天 | 2019-07-03 | 2019-07-07 | ||
| 23 | Generator sets发电机系统 |
79天 | 2019-04-17 | 2019-07-04 | ||
| 24 | Generator seat and support发电机基座及加强 |
31天 | 2019-04-17 | 2019-05-17 | ||
| 25 | Generator installaion安装 |
5天 | 2019-05-29 | 2019-06-02 | ||
| 26 | Cables installation电缆铺设 |
25天 | 2019-05-13 | 2019-06-06 | ||
| 27 | Commissioning调试 |
15天 | 2019-06-20 | 2019-07-04 | ||
| 28 | Mooring winches绞车 |
95天 | 2019-05-08 | 2019-08-10 | ||
| 29 | Winches foundation绞车基座 |
48天 | 2019-05-08 | 2019-06-24 | ||
| 30 | Winches installation安装 |
18天 | 2019-06-20 | 2019-07-07 | ||
| 31 | Cables installation电缆铺设 |
16天 | 2019-07-04 | 2019-07-19 | ||
| 32 | Commissioning调试 |
12天 | 2019-07-30 | 2019-08-10 | ||
| 33 | Anchor Winches锚机 |
138天 | 2019-04-17 | 2019-09-01 | ||
| 34 | Winches foundation锚机基座 |
138天 | 2019-04-17 | 2019-09-01 | ||
| 35 | Winches installation锚机安装 |
18天 | 2019-06-12 | 2019-06-29 | ||
| 36 | Cables installation电缆铺设 |
16天 | 2019-06-20 | 2019-07-05 | ||
| 37 | Chain installtion锚链安装 |
5天 | 2019-07-09 | 2019-07-13 | ||
| 38 | Anchor installation锚安装 |
2天 | 2019-07-30 | 2019-07-31 | ||
| 39 | Commissioning调试 |
4天 | 2019-08-04 | 2019-08-07 | ||
| 40 | Sewage equipments污水处理 |
93天 | 2019-04-05 | 2019-07-06 | ||
| 41 | Seat and foundation基座及加强 |
16天 | 2019-04-05 | 2019-04-20 | ||
| 42 | Installation安装 |
14天 | 2019-04-23 | 2019-05-06 | ||
| 43 | Commissioning调试 |
16天 | 2019-06-21 | 2019-07-06 | ||
| 44 | Fresh water maker and sterilizer造水机 |
92天 | 2019-04-06 | 2019-07-06 | ||
| 45 | Seat and foundation基座及加强 |
20天 | 2019-04-06 | 2019-04-25 | ||
| 46 | Installation安装 |
5天 | 2019-05-01 | 2019-05-05 | ||
| 47 | Commissioning调试 |
16天 | 2019-06-21 | 2019-07-06 | ||
| 48 | Pumps泵 |
124天 | 2019-04-11 | 2019-08-12 | ||
| 49 | Seat and foundation基座及加强 |
26天 | 2019-04-11 | 2019-05-06 | ||
| 50 | Installation安装 |
55天 | 2019-04-17 | 2019-06-10 | ||
| 51 | Commissioning调试 |
24天 | 2019-07-20 | 2019-08-12 | ||
| 52 | Pressure tanks压力水柜 |
47天 | 2019-05-04 | 2019-06-19 | ||
| 53 | Seat and foundation基座及加强 |
12天 | 2019-05-04 | 2019-05-15 | ||
| 54 | Installation安装 |
6天 | 2019-05-24 | 2019-05-29 | ||
| 55 | Commissioning调试 |
17天 | 2019-06-03 | 2019-06-19 | ||
| 56 | Fans 风机 |
41天 | 2019-06-10 | 2019-07-20 | ||
| 57 | Installation安装 |
21天 | 2019-06-10 | 2019-06-30 | ||
| 58 | Commissioning调试 |
12天 | 2019-07-09 | 2019-07-20 | ||
| 59 | AC空调 |
57天 | 2019-06-19 | 2019-08-14 | ||
| 60 | Installation安装 |
24天 | 2019-06-19 | 2019-07-12 | ||
| 61 | Cables connection电缆铺设 |
12天 | 2019-07-02 | 2019-07-13 | ||
| 62 | Commissioning调试 |
16天 | 2019-07-30 | 2019-08-14 | ||
| 63 | MSB主配电板 |
87天 | 2019-05-13 | 2019-08-07 | ||
| 64 | Installation安装 |
5天 | 2019-05-29 | 2019-06-02 | ||
| 65 | Cables connection电缆铺设 |
25天 | 2019-05-13 | 2019-06-06 | ||
| 66 | Commissioning调试 |
23天 | 2019-07-16 | 2019-08-07 | ||
| 67 | Outfitting items舾装 |
59天 | 2019-06-22 | 2019-08-19 | ||
| 68 | Piping supply管系统 |
33天 | 2019-06-29 | 2019-07-31 | ||
| 69 | sanitary unit卫生单元 |
12天 | 2019-06-22 | 2019-07-03 | ||
| 70 | Laundry equipment洗衣设备 |
19天 | 2019-07-11 | 2019-07-29 | ||
| 71 | Room pannel墙板 |
20天 | 2019-07-18 | 2019-08-06 | ||
| 72 | Deck cover甲板敷料 |
19天 | 2019-07-25 | 2019-08-12 | ||
| 73 | Light etc.照明系统 |
33天 | 2019-07-18 | 2019-08-19 | ||
| 74 | Electrical reference电气相关 |
47天 | 2019-07-06 | 2019-08-21 | ||
| 75 | Normal light日常照明 |
33天 | 2019-07-18 | 2019-08-19 | ||
| 76 | FIRE ALARM / GENERAL ALARM火警通用报警 |
12天 | 2019-07-19 | 2019-07-30 | ||
| 77 | NAVIGATION / WIRELESS EQUIPMENT通讯导航设备 |
6天 | 2019-07-25 | 2019-07-30 | ||
| 78 | INNER COMMUNICATION EQUIPMENT 内通系统 |
12天 | 2019-08-10 | 2019-08-21 | ||
| 79 | CONTROL BOX控制盒 |
26天 | 2019-07-06 | 2019-07-31 | ||
| 80 | Sea trial海试 |
3天 | 2019-09-05 | 2019-09-07 | ||
| 81 | Delivery交付 |
2天 | 2019-09-15 | 2019-09-16 |
局部效果预览，详细内容请下载附件查看
