项目项目
| 文件编号 | 2299 | 工期 | 781天 | 开始时间 | 2016-12-12 | 结束时间 | 2019-01-31 |
| 任务数 | 152K | 整理日期 | 2019/5/17 | 下载次数 | 3890次 | ||
| 下载地址 | 计划文件点击下载(登录后才可以下载) | ||||||
计划内容
| 项目 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
编号 |
任务名称 |
工期 |
开始时间 |
结束时间 |
前置任务 |
资源名称 |
| 1 | 生活临建1期/living temporary facility 1 stage |
60天 | 2016-12-12 | 2017-02-09 | ||
| 2 | 生活临建二期/living temporary facility 2 stage |
90天 | 2017-05-21 | 2017-08-18 | 1[FS+100] | |
| 3 | 早期生产临建 teporary facility(for construction) 1 stage |
30天 | 2017-02-10 | 2017-03-11 | 1 | |
| 4 | 10号燃气轮机房钢结构（主结构）10 GT Building steel structure |
89天 | 2017-02-12 | 2017-05-11 | 5[FS+21] | |
| 5 | GT>G(1&2)临时道路、GT/GTG就位GT>G on foundation, temporary road,preparation |
41天 | 2016-12-12 | 2017-01-21 | ||
| 6 | 二次灌浆 second grounting |
14天 | 2017-05-12 | 2017-05-25 | 4 | |
| 7 | 檩条及屋面安装purline and roof installation |
20天 | 2017-05-26 | 2017-06-14 | 6 | |
| 8 | 主厂房断水 anti-rain completion |
0天 | 2017-06-14 | 2017-06-14 | 7 | |
| 9 | 主厂房围护结构施工 MPB enclosure installation |
40天 | 2017-06-15 | 2017-07-24 | 8 | |
| 10 | 10主厂房封闭 10 MBP enclosed |
0天 | 2017-11-26 | 2017-11-26 | 11 | |
| 11 | 10号主厂房围护结构10 MPB enclosure installation |
30天 | 2017-10-28 | 2017-11-26 | 12 | |
| 12 | 10号主厂房断水 10 MPB anti-rain completion |
0天 | 2017-10-27 | 2017-10-27 | 13 | |
| 13 | 檩条及屋面安装Purline and roof installation |
21天 | 2017-10-07 | 2017-10-27 | 14 | |
| 14 | 二次灌浆 second grouting |
14天 | 2017-09-23 | 2017-10-06 | 15 | |
| 15 | 10号主厂房钢结构安装（汽轮机）10 MPB steel structure installation(ST) |
60天 | 2017-07-25 | 2017-09-22 | 16 | |
| 16 | 11号主厂房封闭 11 MPB enclosed |
0天 | 2017-07-24 | 2017-07-24 | 9 | |
| 17 | 12号燃机、发电机找平找正 12 GT>G alignment |
30天 | 2017-06-15 | 2017-07-14 | 8 | |
| 18 | 二次灌浆完成 second grouting completion |
0天 | 2017-07-14 | 2017-07-14 | 17 | |
| 19 | 其它模块就位 other module on foundation |
30天 | 2017-06-15 | 2017-07-14 | 8 | |
| 20 | 12号燃机、发电机本体燃料供应管道 Fuel Gas supply pipe installation |
116天 | 2017-07-15 | 2017-11-07 | 19 | |
| 21 | 压力试验 hydro test |
14天 | 2017-11-08 | 2017-11-21 | 20 | |
| 22 | 润滑油循环 lube oil circulation |
65天 | 2017-11-22 | 2018-01-25 | 23,87,21 | |
| 23 | 12#燃气轮机安装 12 GT installation |
120天 | 2017-07-15 | 2017-11-11 | 18 | |
| 24 | 12#旁路烟卤、扩散器安装 12 bypass stack ,diffuser installation |
90天 | 2017-04-06 | 2017-07-04 | 5[FS+74] | |
| 25 | 10配电室钢结构安装及基础二次灌浆10electrical building steel structure and second grounting |
67天 | 2017-02-12 | 2017-04-19 | 5[FS+21] | |
| 26 | 围护结构施工cladding work |
90天 | 2017-04-20 | 2017-07-18 | 25 | |
| 27 | 具备进盘柜条件 ready for the cabinets |
0天 | 2017-07-28 | 2017-07-28 | 26[FS+10] | |
| 28 | 暖通安装ventilation and air-conditioning |
25天 | 2017-07-19 | 2017-08-12 | 26 | |
| 29 | 11号锅炉施工准备 11 HRSG construction preparation |
10天 | 2017-08-14 | 2017-08-23 | 4[FS+94] | |
| 30 | 11号锅炉钢架及护板吊装11 HRSG steelstructure and guard board installation |
90天 | 2017-08-24 | 2017-11-21 | 29 | |
| 31 | 模块安装 module inatallation |
50天 | 2017-11-22 | 2018-01-10 | 30 | |
| 32 | 水压试验 hydraulic pressure test |
60天 | 2018-07-15 | 2018-09-12 | 58,50,35 | |
| 33 | 汽包就位 steam drum on position |
30天 | 2018-01-11 | 2018-02-09 | 31 | |
| 34 | 二次钢结构（顶棚、平台、楼梯等）other steel structure (ceiling ,platform,ladder) |
80天 | 2018-02-10 | 2018-04-30 | 33 | |
| 35 | 本体管道安装 Main pipe installation |
155天 | 2018-02-10 | 2018-07-14 | 33 | |
| 36 | 11号锅炉保温 11 HRSG insulation |
61天 | 2018-09-13 | 2018-11-12 | 139 | |
| 37 | 酸洗结束 acid cleaning completion |
0天 | 2018-11-12 | 2018-11-12 | 60,47,139[FS+61] | |
| 38 | 吹管 steam blowing |
30天 | 2018-11-13 | 2018-12-12 | 37 | |
| 39 | 11#锅炉烟卤安装 11 HRSG stack installation |
60天 | 2017-09-23 | 2017-11-21 | 29[FS+30] | |
| 40 | 汽轮机平台安装 ST steel platform instalation |
95天 | 2017-10-28 | 2018-01-30 | 12 | |
| 41 | 汽轮机基础准备 preparation for the foudation of ST |
14天 | 2018-01-31 | 2018-02-13 | 40 | |
| 42 | 汽轮机轴承座安装 ST bearing pedestal&supports installation |
36天 | 2018-02-14 | 2018-03-21 | 41 | |
| 43 | 汽轮机及发电机安装 ST & STG installation |
180天 | 2018-03-22 | 2018-09-17 | 42 | |
| 44 | 润滑系统冲洗 lube oil flusing |
47天 | 2018-08-19 | 2018-10-04 | 81 | |
| 45 | 轴系调整STG shaft alingnemt |
30天 | 2018-09-18 | 2018-10-17 | 43 | |
| 46 | 汽轮机保温 ST insulation |
30天 | 2018-08-19 | 2018-09-17 | 81 | |
| 47 | 盘车 turinng gear |
7天 | 2018-10-18 | 2018-10-24 | 45,44,46 | |
| 48 | 氢气站设备及管道安装 H2 building equipment and pipe |
105天 | 2017-08-20 | 2017-12-02 | 51 | |
| 49 | 辅助锅炉安装 auxiliary boiler installation |
15天 | 2017-12-20 | 2018-01-03 | ||
| 50 | 辅助锅炉附属设备及蒸汽管道安装other equipment and steam pipe installation(auxiliary) |
180天 | 2018-01-04 | 2018-07-02 | 49 | |
| 51 | 氢气站厂房安装及围护H2 steelstructure and enclosure installation |
37天 | 2017-07-14 | 2017-08-19 | ||
| 52 | 空压站设备安装air compressor building equipment installation |
45天 | 2017-03-30 | 2017-05-13 | ||
| 53 | 空压系统管道安装air compressor building pipe installation |
259天 | 2017-05-14 | 2018-01-27 | 52 | |
| 54 | 化学站 加药装置设备安装 chemical dosing building equipment installation |
180天 | 2017-08-01 | 2018-01-27 | ||
| 55 | 闭式循环水系统设备安装（单循环）CCW equipment installatin(simple circle) |
15天 | 2017-06-13 | 2017-06-27 | 57[FS+11] | |
| 56 | 闭式循环水管道安装（单循环）CCW pipe installation(simple circle) |
207天 | 2017-07-19 | 2018-02-10 | 55[FS+21] | |
| 57 | 冷却塔安装（单循环）(FIN fan cooler simple cycle) |
58天 | 2017-04-05 | 2017-06-01 | ||
| 58 | 11给水泵房给水设备、管道安装 feedwater equipment and pipe installation |
180天 | 2017-12-24 | 2018-06-21 | ||
| 59 | 水处理站钢结构施工（围护结构完成）water treatment building steel structrue（enclosed) |
90天 | 2017-10-13 | 2018-01-10 | ||
| 60 | #高、中、低压、旁路、冷再热蒸汽管道安装 hight,middle,low bypass and reheat steam pipe installation |
245天 | 2018-02-10 | 2018-10-12 | 33 | |
| 61 | 厂区消防管网安装（单循环）plant firfighting pipe(simple cycle) |
199.50天 | 2017-07-05 | 2018-01-20 | ||
| 62 | 联合循环消防管道fire fighting pipes combined cycle |
127天 | 2017-11-29 | 2018-04-04 | ||
| 63 | 燃气机保温 GT insulation |
40天 | 2017-11-12 | 2017-12-21 | 23 | |
| 64 | 主烟囱保温、油漆 main stack insulation and painting |
35天 | 2018-04-11 | 2018-05-15 | 90 | |
| 65 | 行政楼设备、暖通，消防管道及其他安装 administration building ventination air conditioning firefighting system |
84天 | 2017-10-09 | 2017-12-31 | ||
| 66 | 空压站暖通安装 air compressor building ventination air conditioning |
35天 | 2017-04-14 | 2017-05-18 | 52[SS+15] | |
| 67 | 燃机楼暖通安装 GT building ventination air conditioning |
35天 | 2017-07-25 | 2017-08-28 | 16 | |
| 68 | 车间消防安装work shop firfighting installation |
40天 | 2017-10-28 | 2017-12-06 | 16[FS+95] | |
| 69 | 11#燃气轮机安装 11 GT installation |
100天 | 2017-07-30 | 2017-11-06 | 84 | |
| 70 | 11#燃气轮机保温12 GT insulation |
40天 | 2017-11-07 | 2017-12-16 | 69 | |
| 71 | 11#燃气机进风系统钢结构 11 GT air inlet system steel structure |
55天 | 2017-07-10 | 2017-09-02 | 85 | |
| 72 | 11#燃机进风系统安装 11 GT air inlet system mechenical installation |
110天 | 2017-09-03 | 2017-12-21 | 71 | |
| 73 | 11#燃机、发电机找平找正11 GT & GTG alinment |
30天 | 2017-06-30 | 2017-07-29 | 8[SS+15] | |
| 74 | 其他模块 Other module |
30天 | 2017-06-30 | 2017-07-29 | 8[SS+15] | |
| 75 | 11号燃机、发电机本体燃料供应管道 11 GT GTG fuel oil supply pipe installation |
110天 | 2017-07-30 | 2017-11-16 | 74 | |
| 76 | 压力试验 hydro test |
15天 | 2017-11-17 | 2017-12-01 | 75 | |
| 77 | 润滑油循环 lube oil circle |
65天 | 2017-12-02 | 2018-02-04 | 76,89,69 | |
| 78 | 生产临建二期 temporary facility (for construction)2 stage |
90天 | 2017-05-21 | 2017-08-18 | 3[FS+70] | |
| 79 | 行车安装就位 travelling crane installation |
21天 | 2017-05-26 | 2017-06-15 | 6 | |
| 80 | 行车安装就位 travelling crane installation |
21天 | 2017-10-07 | 2017-10-27 | 14 | |
| 81 | 汽轮机辅助设备及管道安装 ST auxiliary equipment and pipe installation |
150天 | 2018-03-22 | 2018-08-18 | 42 | |
| 82 | 12#进风系统钢结构 12GT air intake system steelstructure installation |
55天 | 2017-07-05 | 2017-08-28 | 24 | |
| 83 | 12#燃机进风系统安装 12GT air intake system mechenical installation |
110天 | 2017-08-29 | 2017-12-16 | 82 | |
| 84 | 二次灌浆完成 second grouting |
0天 | 2017-07-29 | 2017-07-29 | 73 | |
| 85 | 11#旁路烟卤、扩散器安装 11bypass stack,diffuser installation |
90天 | 2017-04-11 | 2017-07-09 | 24[SS+5] | |
| 86 | 12燃机,、发电机油系统管道安装 12 GT,GTG oil system pipe installation |
114天 | 2017-07-15 | 2017-11-05 | 19 | |
| 87 | 压力试压 hydro test |
10天 | 2017-11-06 | 2017-11-15 | 86 | |
| 88 | 11燃机,、发电机油系统管道安装 11 GT,GTG oil system pipe instalation |
110天 | 2017-07-30 | 2017-11-16 | 74 | |
| 89 | 压力试验hydro test |
10天 | 2017-11-17 | 2017-11-26 | 88 | |
| 90 | 上部锅炉烟囱安装 upper main stack installation |
60天 | 2018-02-10 | 2018-04-10 | 39,33 | |
| 91 | 进出口烟道、膨胀节安装 inlet and outlet expansion joint and duct |
70天 | 2018-01-11 | 2018-03-21 | 31 | |
| 92 | 12#锅炉准备施工 12 HRSG installation preparation |
10天 | 2017-09-08 | 2017-09-17 | 29[SS+25] | |
| 93 | 12号锅炉钢架及护板吊装 12 HRSG steelstruture and guard board installtion |
80天 | 2017-09-18 | 2017-12-06 | 92 | |
| 94 | 12#锅炉烟卤安装 12 main stack installation |
60天 | 2017-10-08 | 2017-12-06 | 92[FS+20] | |
| 95 | 模块安装 boiler moudle installation |
50天 | 2017-12-07 | 2018-01-25 | 93 | |
| 96 | 汽包就位 steam drum on position |
30天 | 2018-01-26 | 2018-02-24 | 95 | |
| 97 | 上部锅炉烟囱安装 upper main stack installation |
60天 | 2018-01-06 | 2018-03-06 | 94[FS+30] | |
| 98 | 本体管道安装 HRSG pipe installation |
155天 | 2018-02-25 | 2018-07-29 | 96 | |
| 99 | 进出口烟道、膨胀节安装 inlet and outlet expasion jont and duct |
70天 | 2017-12-07 | 2018-02-14 | 93 | |
| 100 | 主烟囱保温、油漆 main stack insulation and painting |
35天 | 2018-03-07 | 2018-04-10 | 97 | |
| 101 | 二次钢结构（顶棚、平台、楼梯等）other steel structure (ceiling ,platform,ladder) |
80天 | 2018-02-25 | 2018-05-15 | 96 | |
| 102 | 水压试验 hydraulic pressure test |
60天 | 2018-07-30 | 2018-09-27 | 141,98 | |
| 103 | 12号锅炉保温 12 HRSG insulation |
60天 | 2018-09-28 | 2018-11-26 | 104 | |
| 104 | 水压试验结束 11 hydraulic test completion |
0天 | 2018-09-27 | 2018-09-27 | 102 | |
| 105 | 吹管 steam blowing |
30天 | 2019-01-02 | 2019-01-31 | 38[FS+20] | |
| 106 | 11余热锅炉辅机系统 HRSG auxiliary system |
40天 | 2018-05-01 | 2018-06-09 | 34 | |
| 107 | 12余热锅炉辅机系统 HRSG auxiliary system |
40天 | 2018-05-16 | 2018-06-24 | 101 | |
| 108 | ACC钢结构施工3#-5#部分（立柱、桁架、风机、翅片、排气管等）ACC AXI 3-5(including inside equipment and pipe) |
90天 | 2017-11-24 | 2018-02-21 | ||
| 109 | ACC钢结构施工1#-3#部分（立柱、桁架、风机、翅片、排气管、挡风墙等）ACC AXI 1-3(including inside equipment and pipe) |
90天 | 2018-02-22 | 2018-05-22 | 108 | |
| 110 | ACC钢结构施工5#-7#部分（立柱、桁架、风机、翅片、排气管、挡风墙等）ACC AXI 5-7(including inside equipment and pipe) |
90天 | 2018-05-23 | 2018-08-20 | 109 | |
| 111 | 调试、试压、清洗 commissioning, pressure test,cleaning |
30天 | 2018-08-21 | 2018-09-19 | 112[FF],110 | |
| 112 | 辅助设备安装及管道auxiliary equipment and condensate and other pipes installation |
190天 | 2018-02-22 | 2018-08-30 | 109[SS] | |
| 113 | 危险品仓库钢结构 dangrous device warehouse steelstructure |
38天 | 2017-08-01 | 2017-09-07 | ||
| 114 | 工作间钢结构 work shop warehouse steelstrucrue |
72天 | 2017-05-30 | 2017-08-09 | ||
| 115 | 综合管廊钢结构 common pipe rack steel structure |
94天 | 2017-05-16 | 2017-08-17 | ||
| 116 | 燃气站钢结构 Fuel gas station steel structure(enclosed) |
80天 | 2017-07-14 | 2017-10-01 | ||
| 117 | 氢气瓶存放区钢结构 H2 boltle storage building steel structure |
130天 | 2017-04-15 | 2017-08-22 | ||
| 118 | 氮气瓶存放区钢结构N2 bottle storage building steel structure |
68天 | 2017-04-07 | 2017-06-13 | ||
| 119 | CO2气瓶存放区 CO2 bottle storage steel structure |
58天 | 2017-04-17 | 2017-06-13 | ||
| 120 | 11,12单元燃气轮发电机断路器房钢结构11,12 GTG outlet break building steelstructure |
60天 | 2017-07-17 | 2017-09-14 | ||
| 121 | 气体绝缘设备变电站钢结构 GIS substation steelstructure |
80天 | 2017-08-07 | 2017-10-25 | ||
| 122 | 停车场钢结构 Car parking steelstructure |
58天 | 2017-07-26 | 2017-09-21 | ||
| 123 | 11、12燃机平台钢结构及罩壳 11、12 GT platform steelstruture |
60天 | 2017-07-15 | 2017-09-12 | 18 | |
| 124 | 油桶存储区钢结构 oil bucket storage steel structure |
58天 | 2017-05-31 | 2017-07-27 | ||
| 125 | 仓库钢结构 warehouse steel structure |
72天 | 2017-10-19 | 2017-12-29 | ||
| 126 | 瞭望塔钢结构 watch tower steel structure |
30天 | 2017-01-07 | 2017-02-05 | ||
| 127 | 空气冷凝系统配电房钢结构 ACC electricla building steel structrue |
63天 | 2017-11-04 | 2018-01-05 | ||
| 128 | 10单元汽轮机发电机断路器房钢结构 10 ST GTG outlet break building steelstructure |
58天 | 2017-09-08 | 2017-11-04 | ||
| 129 | 燃气站设备安装 fuel gas station equipment installation |
110天 | 2017-10-02 | 2018-01-19 | 116 | |
| 130 | 厂区燃气管道安装 plant fuel gas pipe installation |
153天 | 2017-08-18 | 2018-01-17 | ||
| 131 | 具备单循环条件 ready for commissioning of simple cycle |
0天 | 2018-03-08 | 2018-03-08 | 144,145,149,150,147,143,142,77,22,61,56,53,72,63,83,132,54,48 | |
| 132 | 漏气试验 leakage test |
25天 | 2018-01-18 | 2018-02-11 | 130 | |
| 133 | 水处理设备及管道安装 watertreatment equipment and pipe installation |
116天 | 2018-01-11 | 2018-05-06 | 59 | |
| 134 | 消防安装firefighting |
40天 | 2017-09-12 | 2017-10-21 | 28[FS+30] | |
| 135 | 20电气楼施工及二次灌浆 20 electrical building steelstructure erection and second grounting |
60天 | 2017-04-20 | 2017-06-18 | 25 | |
| 136 | 围护结构施工cladding work |
90天 | 2017-06-19 | 2017-09-16 | 135 | |
| 137 | 暖通施工ventination and air conditioning |
25天 | 2017-09-17 | 2017-10-11 | 136 | |
| 138 | 消防安装firefighting erection |
40天 | 2017-10-12 | 2017-11-20 | 137 | |
| 139 | 水压结束 hydraulic test completion |
0天 | 2018-09-12 | 2018-09-12 | 32 | |
| 140 | 酸洗结束acid cleaning completion |
0天 | 2018-11-12 | 2018-11-12 | 104[FS+46] | |
| 141 | 12给水泵房给水设备、管道安装 12feedwater equipment and pipe installation |
150天 | 2018-01-30 | 2018-06-28 | ||
| 142 | 软化水管道安装DEMI water distribution pipes |
154天 | 2017-09-12 | 2018-02-12 | ||
| 143 | 原水管道 raw water pipes erection |
134天 | 2017-10-02 | 2018-02-12 | ||
| 144 | 井水管道well water pipe |
104天 | 2017-09-24 | 2018-01-05 | ||
| 145 | 工业水管道安装service water pipes erection |
137天 | 2017-10-17 | 2018-03-02 | ||
| 146 | 饮用水管道potable water pipes erection |
148天 | 2017-10-17 | 2018-03-13 | ||
| 147 | 氢气管道安装H2 pipes erection plant area |
148天 | 2017-09-23 | 2018-02-17 | ||
| 148 | 燃油输送站fuel oil forwarding building equipment |
20天 | 2017-10-12 | 2017-10-31 | ||
| 149 | 加热器HEATER |
30天 | 2018-02-07 | 2018-03-08 | 148 | |
| 150 | 厂区燃油管道Plant fuel oil pipes |
210天 | 2017-08-03 | 2018-02-28 | ||
| 151 | 冷却塔（联合循环）Fin fan Cooler for ST combined cycle |
73天 | 2017-04-05 | 2017-06-16 | ||
| 152 | 闭式循环管道安装CCW cooling water pipe for ST(combined cycle) |
181天 | 2018-01-10 | 2018-07-09 | 151 |
局部效果预览，详细内容请下载附件查看
