项目项目
| 文件编号 | 2297 | 工期 | 727天 | 开始时间 | 2016-12-12 | 结束时间 | 2018-12-08 |
| 任务数 | 144K | 整理日期 | 2019/5/17 | 下载次数 | 3890次 | ||
| 下载地址 | 计划文件点击下载(登录后才可以下载) | ||||||
计划内容
| 项目 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
编号 |
任务名称 |
工期 |
开始时间 |
结束时间 |
前置任务 |
资源名称 |
| 1 | 生活临建1期/living temporary facility 1 stage |
50天 | 2016-12-12 | 2017-01-30 | ||
| 2 | 生活临建二期/living temporary facility 2 stage |
90天 | 2017-06-20 | 2017-09-17 | 1[FS+140] | |
| 3 | 早期生产临建 teporary facility(for construction) 1 stage |
30天 | 2017-01-31 | 2017-03-01 | 1 | |
| 4 | 10号燃气轮机房钢结构（主结构）10 GT Building steel structure |
89天 | 2017-02-21 | 2017-05-20 | 5[FS+35] | |
| 5 | GT>G(1&2)临时道路、GT/GTG准备工作GT>G temporary road,preparation |
36天 | 2016-12-12 | 2017-01-16 | ||
| 6 | 二次灌浆 second grounting |
14天 | 2017-05-21 | 2017-06-03 | 4 | |
| 7 | 檩条及屋面安装purline and roof installation |
30天 | 2017-06-04 | 2017-07-03 | 6 | |
| 8 | 主厂房断水 anti-rain completion |
0天 | 2017-07-03 | 2017-07-03 | 7 | |
| 9 | 主厂房围护结构施工 MPB enclosure installation |
30天 | 2017-07-04 | 2017-08-02 | 8 | |
| 10 | 10主厂房封闭 10 MBP enclosed |
0天 | 2017-12-10 | 2017-12-10 | 11 | |
| 11 | 10号主厂房围护结构10 MPB enclosure installation |
35天 | 2017-11-06 | 2017-12-10 | 12 | |
| 12 | 10号主厂房断水 10 MPB anti-rain completion |
0天 | 2017-11-05 | 2017-11-05 | 13 | |
| 13 | 檩条及屋面安装Purline and roof installation |
21天 | 2017-10-16 | 2017-11-05 | 14 | |
| 14 | 二次灌浆 second grouting |
14天 | 2017-10-02 | 2017-10-15 | 15 | |
| 15 | 10号主厂房钢结构安装（汽轮机）10 MPB steel structure installation(st) |
60天 | 2017-08-03 | 2017-10-01 | 16 | |
| 16 | 11号主厂房封闭 11 MPB enclosed |
0天 | 2017-08-02 | 2017-08-02 | 9 | |
| 17 | 11号燃机、发电机找平找正 11 GT>G alignment |
30天 | 2017-07-04 | 2017-08-02 | 8 | |
| 18 | 二次灌浆完成 second grouting completion |
0天 | 2017-08-02 | 2017-08-02 | 17 | |
| 19 | 其它模块就位 other module on foundation |
30天 | 2017-07-04 | 2017-08-02 | 8 | |
| 20 | 11号燃机、发电机本体燃料供应管道 Fuel Gas supply pipe installation |
100天 | 2017-08-03 | 2017-11-10 | 19 | |
| 21 | 油循环oil circulation |
70天 | 2017-12-11 | 2018-02-18 | 93,96,73,20 | |
| 22 | 11#燃气轮机安装 11 GT installation |
90天 | 2017-08-03 | 2017-10-31 | 18 | |
| 23 | 11#旁路烟卤、扩散器安装 11 bypass stack ,diffuser installation |
90天 | 2017-04-06 | 2017-07-04 | 5[FS+79] | |
| 24 | 配电室钢结构安装及基础灌浆electrical building steel structure and foundation |
60天 | 2017-02-21 | 2017-04-21 | 5[FS+35] | |
| 25 | 楼面施工 floor construction |
30天 | 2017-04-22 | 2017-05-21 | 24 | |
| 26 | 具备楼面浇注条件 ready for grouting |
0天 | 2017-05-21 | 2017-05-21 | 25 | |
| 27 | 围护结构施工 enclosure structure construction |
60天 | 2017-05-22 | 2017-07-20 | 26 | |
| 28 | 具备进盘柜条件 ready for the cabinets |
0天 | 2017-08-05 | 2017-08-05 | 27[FS+15] | |
| 29 | 暖通、消防安装ventilation and air-conditioning firefighting |
49天 | 2017-07-21 | 2017-09-07 | 27 | |
| 30 | 11号锅炉施工准备 11 HRSG construction preparation |
15天 | 2017-06-20 | 2017-07-04 | 4[FS+30] | |
| 31 | 11号锅炉钢架及护板吊装11 HRSG steelstructure and guard board installation |
90天 | 2017-07-05 | 2017-10-02 | 30 | |
| 32 | 模块安装 module inatallation |
30天 | 2017-10-03 | 2017-11-01 | 31 | |
| 33 | 水压试验结束 hydraulic pressure test completion |
0天 | 2018-06-29 | 2018-06-29 | 34 | |
| 34 | 水压试验 hydraulic pressure test |
60天 | 2018-05-01 | 2018-06-29 | 65,69,37 | |
| 35 | 汽包就位 steam drum on position |
30天 | 2017-11-02 | 2017-12-01 | 32 | |
| 36 | 二次钢结构（顶棚、平台、楼梯等）other steel structure (ceiling ,platform,ladder) |
60天 | 2018-01-11 | 2018-03-11 | 99 | |
| 37 | 本体管道安装 Main pipe installation |
150天 | 2017-12-02 | 2018-04-30 | 35 | |
| 38 | 11号锅炉保温 11 HRSG insulation |
61天 | 2018-06-30 | 2018-08-29 | 33 | |
| 39 | 酸洗结束 acid cleaning completion |
0天 | 2018-10-09 | 2018-10-09 | 50,38[FS+30] | |
| 40 | 吹管 steam blowing |
30天 | 2018-10-10 | 2018-11-08 | 39 | |
| 41 | 11#锅炉烟卤安装 11 HRSG stack installation |
60天 | 2017-09-03 | 2017-11-01 | 30[FS+60] | |
| 42 | 汽轮机平台安装 ST steel platform instalation |
95天 | 2017-11-06 | 2018-02-08 | 12 | |
| 43 | 汽轮机基础准备 preparation for the foudation of ST |
14天 | 2018-02-09 | 2018-02-22 | 42 | |
| 44 | 汽轮机轴承座安装 ST bearing pedestal installation |
30天 | 2018-02-23 | 2018-03-24 | 43 | |
| 45 | 汽轮机底座就位调整 ST pedestal adjustment |
90天 | 2018-03-25 | 2018-06-22 | 44 | |
| 46 | 汽轮机保温 ST insulation |
20天 | 2018-07-13 | 2018-08-01 | 91 | |
| 47 | 汽轮机闭式循环水冷却塔、辅助设备安装（联合循环）cooling tower ,auxiliary equipment(combined cycle) |
73天 | 2017-09-20 | 2017-12-01 | 72[FS+33] | |
| 48 | 发电机调整 GTG adjutment |
42天 | 2018-06-23 | 2018-08-03 | 45 | |
| 49 | 润滑系统冲洗 lube oil flusing |
60天 | 2018-08-04 | 2018-10-02 | 48,46 | |
| 50 | 盘车 turinng gear |
7天 | 2018-10-03 | 2018-10-09 | 49 | |
| 51 | 氢气站设备及管道安装 H2 building equipment and pipe |
105天 | 2017-09-18 | 2017-12-31 | 56 | |
| 52 | 辅助锅炉给水泵房结构安装及维护auxiliary boiler building steel structure |
27天 | 2018-03-20 | 2018-04-15 | 42 | |
| 53 | 辅助锅炉输油泵安装oil delivery pump installation |
60天 | 2018-04-16 | 2018-06-14 | 52 | |
| 54 | 辅助锅炉安装 auxiliary boiler installation |
15天 | 2017-12-11 | 2017-12-25 | 10 | |
| 55 | 辅助锅炉附属设备及管道安装other equipment and pipe installation(auxiliary) |
60天 | 2017-12-26 | 2018-02-23 | 54 | |
| 56 | 氢气站厂房安装及围护H2 steelstructure and enclosure installation |
37天 | 2017-08-12 | 2017-09-17 | ||
| 57 | 空压站设备安装air compressor building equipment installation |
45天 | 2017-07-05 | 2017-08-18 | ||
| 58 | 空压系统管道安装air compressor building pipe installation |
101天 | 2017-08-19 | 2017-11-27 | 57 | |
| 59 | 化学站 加药装置设备安装 chemical dosing building equipment installation |
180天 | 2017-08-01 | 2018-01-27 | ||
| 60 | 闭式循环水系统设备安装（单循环）CCW equipment installatin(simple circle) |
30天 | 2017-08-19 | 2017-09-17 | 62 | |
| 61 | 闭式循环水管道安装（单循环）CCW pipe installation(simple circle) |
140天 | 2017-09-18 | 2018-02-04 | 60 | |
| 62 | 机力冷却塔安装（单循环）(cooling tower simple circle) |
60天 | 2017-06-20 | 2017-08-18 | ||
| 63 | 冷却水系统管道安装（联合循环）(cooling system pipe installation(combined circle) |
237天 | 2017-12-02 | 2018-07-26 | 47 | |
| 64 | 锅炉给水泵房结构施工、围护 feedwater pump building steel structure,enclosure installation |
29天 | 2018-01-20 | 2018-02-17 | ||
| 65 | 给水设备、管道安装 feedwater equipment and pipe installation |
70天 | 2018-02-18 | 2018-04-28 | 64 | |
| 66 | 水处理站钢结构施工（屋面完成）water treatment building steel structrue |
77天 | 2017-08-01 | 2017-10-16 | ||
| 67 | 厂区燃油供应系统 plant fuel gas supply system |
187天 | 2017-08-15 | 2018-02-17 | ||
| 68 | 11#高、中、低压、旁路、冷再热蒸汽管道安装 hight,middle,low bypass and reheat steam pipe installation |
236天 | 2017-12-21 | 2018-08-13 | 35[FS+19] | |
| 69 | 辅助锅炉设备及蒸汽管道安装auxiliary boiler equipment and pipe installation |
163天 | 2017-10-08 | 2018-03-19 | ||
| 70 | 厂区消防管网安装（单循环）plant firfighting pipe(simple circle) |
210天 | 2017-07-01 | 2018-01-26 | ||
| 71 | 燃机CO2消防模块、主变压器消防系统安装 GT& Main transformer firefighting |
45天 | 2017-08-02 | 2017-09-15 | 72[SS+5] | |
| 72 | 燃机消防承压水箱 |
21天 | 2017-07-28 | 2017-08-17 | ||
| 73 | 燃气机保温 GT insulation |
40天 | 2017-11-01 | 2017-12-10 | 22 | |
| 74 | 主烟囱保温、油漆 main stack insulation and painting |
30天 | 2018-01-26 | 2018-02-24 | 98 | |
| 75 | 行政楼设备、管道及其他安装 administration mechenical construction |
210天 | 2017-08-09 | 2018-03-06 | ||
| 76 | 空压站暖通安装 air compressor building ventination air conditioning |
35天 | 2017-07-05 | 2017-08-08 | 57[SS] | |
| 77 | 燃机楼暖通安装 GT building ventination air conditioning |
35天 | 2017-09-10 | 2017-10-14 | 16 | |
| 78 | 车间消防安装work shop firfighting installation |
40天 | 2017-08-30 | 2017-10-08 | 16 | |
| 79 | 氢气站暖通安装 H2 building ventination air conditioning |
62天 | 2017-09-18 | 2017-11-18 | 56 | |
| 80 | 12#燃气轮机安装 12 GT installation |
80天 | 2017-08-18 | 2017-11-05 | 94 | |
| 81 | 12#燃气轮机保温12 GT insulation |
40天 | 2017-11-06 | 2017-12-15 | 80 | |
| 82 | 12#燃气机进风系统钢结构 12 GT air inlet system steel structure |
50天 | 2017-07-20 | 2017-09-07 | 95 | |
| 83 | 12#燃机进风系统安装 12 GT air inlet system mechenical installation |
43天 | 2017-09-08 | 2017-10-20 | 82 | |
| 84 | 12#燃机、发电机找平找正12 GT & GTG alinment |
30天 | 2017-07-19 | 2017-08-17 | 8[SS+15] | |
| 85 | 其他模块 Other module |
30天 | 2017-07-19 | 2017-08-17 | 8[SS+15] | |
| 86 | 12号燃机、发电机本体燃料供应管道 12 GT GTG fuel oil supply pipe installation |
100天 | 2017-08-18 | 2017-11-25 | 85 | |
| 87 | 油循环 oil circle |
65天 | 2017-12-16 | 2018-02-18 | 81,83,97,86 | |
| 88 | 生产临建二期 temporary facility (for construction)2 stage |
90天 | 2017-06-20 | 2017-09-17 | 3[FS+110] | |
| 89 | 行车安装就位 travelling crane installation |
21天 | 2017-06-04 | 2017-06-24 | 6 | |
| 90 | 行车安装就位 travelling crane installation |
21天 | 2017-10-16 | 2017-11-05 | 14 | |
| 91 | 汽轮机辅助设备及管道安装 ST auxiliary equipment and pipe installation |
110天 | 2018-03-25 | 2018-07-12 | 44 | |
| 92 | 11#进风系统钢结构 11GT air inlet system steelstructure installation |
50天 | 2017-07-05 | 2017-08-23 | 23 | |
| 93 | 11#燃机进风系统安装 11GT air inlet system mechenical installation |
43天 | 2017-08-24 | 2017-10-05 | 92 | |
| 94 | 二次灌浆完成 second grouting |
0天 | 2017-08-18 | 2017-08-18 | 84 | |
| 95 | 12#旁路烟卤、扩散器安装 12 bypass stack,diffuser installation |
90天 | 2017-04-21 | 2017-07-19 | 23[SS+15] | |
| 96 | 11燃机,、发电机油系统管道安装 11 GT,GTG oil system pipe installation |
60天 | 2017-08-03 | 2017-10-01 | 19 | |
| 97 | 12燃机,、发电机油系统管道安装 12 GT,GTG oil system pipe instalation |
60天 | 2017-08-18 | 2017-10-16 | 85 | |
| 98 | 上部锅炉烟囱安装 upper main stack installation |
55天 | 2017-12-02 | 2018-01-25 | 41[FS+30] | |
| 99 | 进出口烟道、膨胀节安装 inlet and outlet expansion joint and duct |
40天 | 2017-12-02 | 2018-01-10 | 35 | |
| 100 | 12#锅炉准备施工 12 HRSG installation preparation |
15天 | 2017-07-20 | 2017-08-03 | 30[SS+30] | |
| 101 | 12号锅炉钢架及护板吊装 12 HRSG steelstruture and guard board installtion |
90天 | 2017-08-04 | 2017-11-01 | 100 | |
| 102 | 12#锅炉烟卤安装 12 main stack installation |
60天 | 2017-10-03 | 2017-12-01 | 100[FS+60] | |
| 103 | 模块安装 boiler moudle installation |
30天 | 2017-11-02 | 2017-12-01 | 101 | |
| 104 | 汽包就位 steam drum on position |
30天 | 2017-12-02 | 2017-12-31 | 103 | |
| 105 | 上部锅炉烟囱安装 upper main stack installation |
55天 | 2018-01-01 | 2018-02-24 | 102[FS+30] | |
| 106 | 本体管道安装 HRSG pipe installation |
150天 | 2018-01-01 | 2018-05-30 | 104 | |
| 107 | 进出口烟道、膨胀节安装 inlet and outlet expasion jont and duct |
40天 | 2018-01-01 | 2018-02-09 | 104 | |
| 108 | 主烟囱保温、油漆 main stack insulation and painting |
30天 | 2018-02-25 | 2018-03-26 | 105 | |
| 109 | 二次钢结构（顶棚、平台、楼梯等）other steel structure (ceiling ,platform,ladder) |
60天 | 2018-02-10 | 2018-04-10 | 107 | |
| 110 | 水压试验 hydraulic pressure test |
60天 | 2018-05-31 | 2018-07-29 | 106 | |
| 111 | 12号锅炉保温 12 HRSG insulation |
61天 | 2018-07-30 | 2018-09-28 | 112 | |
| 112 | 水压试验结束 12 hydraulic pressure test completion |
0天 | 2018-07-30 | 2018-07-30 | 110 | |
| 113 | 酸洗结束 acid cleaning completion |
0天 | 2018-11-08 | 2018-11-08 | 40,111[FS+30] | |
| 114 | 吹管 steam blowing |
30天 | 2018-11-09 | 2018-12-08 | 113 | |
| 115 | 11余热锅炉辅机系统 HRSG auxiliary system |
50天 | 2018-03-12 | 2018-04-30 | 36 | |
| 116 | 12余热锅炉辅机系统 HRSG auxiliary system |
50天 | 2018-04-11 | 2018-05-30 | 109 | |
| 117 | 11#余热锅炉给水泵房暖通安装11 HRSG feedwater ventination air conditioning installation |
41天 | 2018-03-20 | 2018-04-29 | 64[FS+30] | |
| 118 | 11#高、中、低压、旁路、冷再热蒸汽管道安装 11 hight, middle, low, bypass, reheat steam pipe installation |
236天 | 2018-01-20 | 2018-09-12 | 104[FS+19] | |
| 119 | ACC钢结构施工3#-5#部分（立柱、桁架、风机、翅片、排气管等）ACC AXI 3-5(including inside equipment and pipe) |
90天 | 2017-10-22 | 2018-01-19 | ||
| 120 | ACC钢结构施工1#-3#部分（立柱、桁架、风机、翅片、排气管、挡风墙等）ACC AXI 1-3(including inside equipment and pipe) |
80天 | 2018-01-20 | 2018-04-09 | 119 | |
| 121 | ACC钢结构施工5#-7#部分（立柱、桁架、风机、翅片、排气管、挡风墙等）ACC AXI 5-7(including inside equipment and pipe) |
70天 | 2018-04-10 | 2018-06-18 | 120 | |
| 122 | 调试、试压、清洗 commissioning, pressure test,cleaning |
30天 | 2018-06-19 | 2018-07-18 | 123[FF],121 | |
| 123 | 辅助设备安装auxiliary equipment installation |
90天 | 2018-04-10 | 2018-07-08 | 120 | |
| 124 | 危险品仓库钢结构 dangrous device warehouse steelstructure |
38天 | 2017-08-01 | 2017-09-07 | ||
| 125 | 工作间钢结构 work shop warehouse steelstrucrue |
109天 | 2017-08-10 | 2017-11-26 | ||
| 126 | 综合管廊钢结构 common pipe rack steel structure |
93天 | 2017-06-01 | 2017-09-01 | ||
| 127 | 燃气站钢结构 Fuel gas station steel structure |
110天 | 2017-05-21 | 2017-09-07 | 4 | |
| 128 | 氢气瓶存放区钢结构 H2 boltle storage building steel structure |
37天 | 2017-09-04 | 2017-10-10 | ||
| 129 | 氮气瓶存放区钢结构N2 bottle storage building steel structure |
36天 | 2017-09-07 | 2017-10-12 | ||
| 130 | CO2气瓶存放区 CO2 bottle storage steel structure |
36天 | 2017-09-10 | 2017-10-15 | ||
| 131 | 12单元燃气轮发电机断路器房钢结构12 GTG outlet break building steelstructure |
67天 | 2017-07-24 | 2017-09-28 | ||
| 132 | 气体绝缘设备变电站钢结构 GIS substation steelstructure |
82天 | 2017-08-07 | 2017-10-27 | ||
| 133 | 停车场钢结构 Car parking steelstructure |
66天 | 2017-12-02 | 2018-02-05 | ||
| 134 | 11&12燃机平台钢结构 11&12 GT platform steel struture |
50天 | 2017-07-15 | 2017-09-02 | 8[FS+11] | |
| 135 | 油桶存储区钢结构 oil bucket storage steel structure |
45天 | 2017-08-28 | 2017-10-11 | ||
| 136 | 仓库钢结构 warehouse steel structure |
120天 | 2017-09-25 | 2018-01-22 | ||
| 137 | 瞭望塔钢结构 watch tower steel structure |
30天 | 2018-01-01 | 2018-01-30 | ||
| 138 | 空气冷凝系统配电房钢结构 ACC electricla building steel structrue |
54天 | 2017-12-03 | 2018-01-25 | ||
| 139 | 10单元汽轮机发电机断路器房钢结构 10 ST GTG outlet break building steelstructure |
45天 | 2017-10-25 | 2017-12-08 | ||
| 140 | 燃气站设备安装 fuel gas station equipment installation |
20天 | 2017-09-08 | 2017-09-27 | 127 | |
| 141 | 厂区燃气管道安装 plant fuel oil pipe installation |
110天 | 2017-09-28 | 2018-01-15 | 140 | |
| 142 | 具备单循环条件 ready for simple circle |
0天 | 2018-02-19 | 2018-02-19 | 58,143,70,67,59,144,61,51,87 | |
| 143 | 漏气试验 leakage test |
25天 | 2018-01-16 | 2018-02-09 | 141 | |
| 144 | 水处理设备管道安装 watertreatment equipment and pipe installation |
120天 | 2017-10-17 | 2018-02-13 | 66 |
局部效果预览，详细内容请下载附件查看
